1.The degreasing cleaning process consists of two parts: chemical decomposition, neutralization, and electrolysis

The cold-rolled steel strip, due to surface contamination such as oil stains, is connected to the tail of the previous coil at the welding machine through an uncoiler, a pinch roller, and a cutting head. It then enters a hot alkali tank through a turning roller, with an alkali concentration of 0.5% -2% and a temperature of around 80 degrees Celsius. After soaking and brushing with alkali, most of the oil stains on the surface are removed, and then enters an electrolytic cleaning tank. The alkali concentration and temperature in the tank are equivalent to those in the hot alkali cleaning tank, Use the oxygen and hydrogen generated by electrolysis to clean the surface of steel plates and improve the cleaning effect

After entering the flushing tank through the turning roller, the residual alkaline solution on the surface of the strip steel is washed clean before entering the dryer

The moisture is dried, rolled neatly by the coiler after passing through the tension roller, and the tail is cut and unloaded.

2.Process flow: uncoiler → 1 # pinch roller → cutting shear → spot welding machine → 2 # pinch roller → turning roller → hot alkali tank

(Two sunken rollers, four pairs of brush rollers) → Squeezing roller → Turning roller → Electrolytic cleaning tank (two sunken rollers, with steel guide

Roll) → Squeezing roller → Washing tank (two pairs of brush rollers, one sinking roller) → Squeezing roller (double squeezing) → Hot air drying

Device → Tension roller → Tail cutting shear → Turning roller → Coiler (with EPC)

3.Technical Parameter:

Processing material: Cold rolled strip steel

Strip steel specification: 0.15~1.4 × 650-1000mm

Inner diameter of steel coil: 508mm

Outer diameter of steel coil: 900~1750mm

Steel coil weight: maximum 15000kg

Linear speed: 180m/min

Design different solutions based on the actual needs of customers such as width, thickness, and output.
